TIANMA 18.5 Inch Industrial LCD Display Panel with 1400cd/m2 Brightness and 3840x2160 UHD Resolution

Name: TIANMA 18.5 Inch Industrial LCD Display Panel with 1400cd/m2 Brightness and 3840x2160 UHD Resolution
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: P1850UHF1MA00
Price: 43.00 USD
Availability: InStock

Nama merek:	TIANMA
Nomor Model:	P1850UHF1MA00
MOQ:	10 buah
harga:	negotiable
Ketentuan Pembayaran:	T/T,W,Western Union,MoneyGram
Kemampuan Pasokan:	3000 pcs per minggu

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

Rohs,CE,FCC

Kualitas:

Baru Asli

kemasan:

Kemasan industri asli

Resolusi:

3840*2160 piksel

Gaya:

IPS 40PIN

Kecerahan:

1400CD/M2

Warna:

1.07B

Rasio Kontras:

1200 :1

kehidupan kerja:

30K Jam

Kemasan rincian:

Kemasan Industri

Deskripsi Produk

TIANMA 18.5-Inch Industrial LCD Display Panel P1850UHF1MA00

Product Overview

The P1850UHF1MA00 is a high-performance 18.5-inch industrial LCD display panel from Tianma Microelectronics Co., Ltd., featuring ultra-high brightness of 1400 cd/m² and UHD resolution (3840×2160 pixels). This panel is specifically designed for demanding industrial and outdoor applications.

Key Specifications

Brand	TIANMA
Model P/N	P1850UHF1MA00
Diagonal Size	18.5"
Panel Type	a-Si TFT-LCD, LCM
Resolution	3840(RGB)×2160 (UHD), 238 PPI
Active Area	408.96(W)×230.04(H) mm
Outline Dimensions	430.96×252.04 mm (H×V×D)
Luminance	1400 cd/m² (Typical)
Contrast Ratio	1200:1 (Typical)
Viewing Angle	88/88/88/88 (Typical, CR≥10)
Color Depth	1.07B colors, 72% NTSC
Backlight	WLED, 20K hours lifespan, No Driver
Refresh Rate	60Hz
Signal Type	eDP, eDP1.2
Touchscreen	Without

Operating Conditions

Operating Temperature	-20°C to 70°C
Storage Temperature	-30°C to 80°C

Key Features

Ultra High Brightness (1400 cd/m²) for outdoor visibility
UHD Resolution (3840×2160) with 238 PPI density
Wide operating temperature range (-20°C to 70°C)
10-bit color depth with 72% NTSC color gamut
WLED backlight with 20,000 hours lifespan
eDP interface (eDP1.2)
Symmetrical viewing angles (88/88/88/88)

Application Areas

Industrial equipment and machinery
Outdoor high-brightness applications
Professional display systems

Note: This model entered mass production in Q3 2025 and is currently in production. Specifications were last updated on October 14, 2025. For integration into your products, we strongly recommend contacting TIANMA or their authorized agents for the latest production status and detailed specifications.
