rincian produk

Rumah Produk

AUO 55inch Stretched LCD Display with 1920*1080pixels Resolution 59Pin Connector and 4000:1 Contrast Ratio for Digital Signage

Nama merek:	AUO
Nomor Model:	C089KAN01.0
MOQ:	10 buah
harga:	negotiable
Ketentuan Pembayaran:	T/T,W,Western Union,MoneyGram
Kemampuan Pasokan:	3000 pcs per minggu

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

Rohs,CE,FCC

Kualitas:

Baru Asli

Kemasan:

Kemasan industri asli

Bahan:

dipimpin kaca

Warna:

16,7 juta

Model:

LCM, TFT

Gaya:

Layar LCD Batang

Resolusi:

1920*1080 Piksel

Kecerahan:

400ccd/m2

Konektor:

59Pin

kehidupan kerja:

30K Jam

Rasio Kontras:

4000:1

Kemasan rincian:

Kemasan Industri

Menyoroti:

1920*1080pixels Stretched LCD Display

59Pin Connector Bar LCD Display

4000:1 Contrast Ratio Digital Signage LCD Display

Deskripsi Produk

AUO 55-inch Digital Signage LCD Display P550HVN06.1

55-inch diagonal a-Si TFT-LCD display panel with 1920*1080 FHD resolution, 40 PPI pixel density, and 59-pin LVDS interface. Designed for digital signage applications with landscape/portrait orientation capability.

Key Features

55-inch display cell without backlight or touch screen
AMVA3 technology with normally black, transmissive display
High contrast ratio of 4000:1 (typical)
Wide viewing angle: 89/89/89/89 (CR≥10)
Built-in driver IC with 12 source + 6 gate chips
Supports 16.7 million colors with 72% NTSC coverage
LVDS signal interface (2 channel, 10-bit)
Operating temperature: 0°C to 50°C

Technical Specifications

Brand	AUO
Model Number	P550HVN06.1 CELL
Diagonal Size	55 inches
Panel Type	a-Si TFT-LCD, CELL, FOB
Resolution	1920(RGB)*1080 (FHD), 40 PPI
Pixel Format	RGB Vertical Stripe
Active Area	1209.6mm * 680.4mm
Outline Dimensions	1228.8mm * 699.4mm * 1.4mm
Surface Reflection	1.45% (Max.)
Contrast Ratio	4000:1 (Typical)
Response Time	8ms (G to G, Typical)
Glass Depth	0.50+0.50 mm
Transmissivity	6.0% (Typical, with Polarizer)
Display Colors	16.7 Million
Backlight	No Backlight (CELL only)
Refresh Rate	60Hz
Touch Screen	Without
Signal Interface	LVDS (2 channel, 10-bit), 59-pin connector
Input Voltage	12.0V (Typical)
Panel Weight	2.53 kg (Typical)

Environmental Specifications

Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C

Application

Important Note: This model entered mass production in Q4 2017 and is now discontinued. For the latest production status and specifications, we strongly recommend contacting AUO or their authorized distributors directly.

The production status information provided on this page is for reference only and should not be used as the sole basis for decision-making. Specifications were last updated on March 7, 2024.
