BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

Nama merek:	BOE
Nomor Model:	DV280FBM-NB1
MOQ:	10 pcs
harga:	negotiable
Rincian kemasan:	Kemasan Industri
Ketentuan Pembayaran:	T/T, W, Western Union, MoneyGram

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Sertifikasi:

Rohs,CE,FCC

Kualitas:

Asli baru

Kemasan:

Kemasan Industri Asli

Bahan:

dipimpin kaca

Warna:

16.7m

Model:

LCM, TFT

Gaya:

Layar LCD Batang

Resolusi:

1920*360 piksel

Kecerahan:

700CCD/M2

Konektor:

51pin

Kehidupan kerja:

50K jam

Rasio Kontras:

1200:1

Ukuran Layar:

28 inci

Menyediakan kemampuan:

3000 pcs per minggu

Deskripsi Produk

BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

DV280FBM-NB1 is a 28.0" diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.0G (9.8 m/s²). It's general features are summarized by Einklcd in the following: Hight Brightness, WLED Backlight, Life ≥ 50K hours, Bar Display , 1/3 cut of 31.5". Based on its features, Einklcd recommend that this model be applied to Digital Signage, Outdoor High Brightness, Stretched Bar LCD etc. According to the information stored in einklcd this model mass production on Q1, 2016, Now this model is in production. We inputted this model's specification on May 23 2016 for the first time, and the latest update on Sep 5 2025. If you want to embed the LCM in your future product, Einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail of DV280FBM-NB1. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand:BOE

Model P/N: DV280FBM-NB1

Diagonal Size 28.0" (1/3 cut of 32.0")

Panel Type: a-Si TFT-LCD, LCM

Resolution1920(RGB)×360 69PPI Pixel

Format RGB Vertical Stripe

Active Area 699.84(W)×131.22(H) mm

Bezel Opening 704(W)×136(H) mm

Outline Size: 732(W)×165(H) ×17.3(D) mm

Brightness:700 cd/m² (Typ.)

Viewing Angle: 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down

Best View on Symmetry

Display Colors: 16.7M 72% NTSC

Frequency 60Hz 120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Weight: 2.40Kgs (Typ.)

Surface

Contrast Ratio:1200:1 (Typ.) (TM)

Display Mode: ADS, Normally Black, Transmissive IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Response Time :8 (Typ.)(G to G)

Lamp Type: WLED , 50K hours , Without Driver

Touch Screen :Without

Application:Digital Signage Outdoor High Brightness Stretched Bar LCD

Signal Interface LVDS (1 ch, 8-bit) , 51 pins Connector

Input Voltage 12.0V (Typ.)

Environment Operating Temp.: 0 ~ 50 °C ;

Storage Temp.: -20 ~ 60 °C

tampilan tipe bar

tampilan monitor peregangan

monitor LCD yang diperpanjang
