AUO 7inch automotive lcd panel Screen Monitor C070VAN02.9 50Pin 480*800pixels 133PPI

Nama merek:	auo
Nomor Model:	C070VAN02.9
MOQ:	10 buah
harga:	negotiable
Rincian kemasan:	Kemasan Industri
Ketentuan Pembayaran:	T/T, W, Western Union, MoneyGram

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Tiongkok

Sertifikasi:

Rohs,CE,FCC

Kualitas:

Asli baru

Kemasan:

Kemasan Industri Asli

Resolusi:

480*800 Piksel

Gaya:

IPS 50pin

Kecerahan:

100 CD/M2

Warna:

16.7m

Rasio Kontras:

100 :1

Kehidupan kerja:

10k jam tanpa driver

Menyediakan kemampuan:

3000 pcs per minggu

Deskripsi Produk

AUO 7inch automotive lcd panel Screen Monitor C070VAN02.9 50Pin 480*800pixels 133PPI

AU Optronics Corp. (hereafter called AUO) C070VAN02.9 is a 7.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of -30 ~ 85°C , a storage temperature range of -40 ~ 95°C , and the maximal vibration level of 2.9G (28.4 m/s²). It's general features are summarized by Einklcd in the following: sRGB, Wide Temperature, 3G Vibration, Ultra High Brightness, WLED Backlight, U/D,L/R Reverse, Matte . Based on its features, Einklcd recommend that this model be applied to Outdoor High Brightness, Automotive Display etc. According to the information stored in einklcd this model mass production on Q3, 2018, Now this model is in production. We inputted this model's specification on Oct 14 2024 for the first time, and the latest update on Jul 22 2025. If you want to embed C070VAN02.9 LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's distributor to learn lateast production and specification detail. The C070VAN02.9 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand:AUO

Model P/N: C070VAN02.9

Diagonal Size: 7.0"

Panel Type: a-Si TFT-LCD, LCM

Resolution: 800×480(RGB), WVGA 133PPI

Pixel Format: RGB Horizontal Stripe

Active Area:152.4(W)×91.44(H) mm

Bezel Opening:155.65(W)×94.04(H) mm

Outline Dim. 167.3(H)×109.2(V) ×9.35(D) mm

Treatment Antiglare

Luminance :1000 cd/m² (Typ.)

Contrast Ratio: 1000:1 (Typ.) (TM)

View Direction: Symmetry

Response Time: 11/9 (Typ.)(Tr/Td)

Viewing Angle: 80/80/80/80 (Typ.)(CR≥10) Left / Right / Up / Down

Operating Mode: AHVA, Normally Black, Transmissive

IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Support Color 16.7M 99% sRGB

Light Source :WLED [7S2P] , 10K hours , W/O Driver

Weight: 166±10g

Designed For: Outdoor High Brightness, Automotive Display

Frame Rate: 60Hz

120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Touch Panel :Without

Interface Type Parallel RGB (1 ch, 8-bit) , 50 pins FPC

Power Supply: 3.3V (Typ.)

Environment Operating Temperature: -30 ~ 85 °C ;

Storage Temperature: -40 ~ 95 °C ;

Vibration Level: 2.9G (28.4 m/s²)

rincian produk

Rumah > Produk >

layar LCD mobil

AUO 7inch automotive lcd panel Screen Monitor C070VAN02.9 50Pin 480*800pixels 133PPI

Semua Kategori

AUO 7inch automotive lcd panel Screen Monitor C070VAN02.9 50Pin 480*800pixels 133PPI

Nama merek:	auo
Nomor Model:	C070VAN02.9
MOQ:	10 buah
harga:	negotiable
Rincian kemasan:	Kemasan Industri
Ketentuan Pembayaran:	T/T, W, Western Union, MoneyGram

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Tiongkok

Nama merek:

auo

Sertifikasi:

Rohs,CE,FCC

Nomor model:

C070VAN02.9

Kualitas:

Asli baru

Kemasan:

Kemasan Industri Asli

Resolusi:

480*800 Piksel

Gaya:

IPS 50pin

Kecerahan:

100 CD/M2

Warna:

16.7m

Rasio Kontras:

100 :1

Kehidupan kerja:

10k jam tanpa driver

Kuantitas min Order:

10 buah

Harga:

negotiable

Kemasan rincian:

Kemasan Industri

Waktu pengiriman:

4-5 hari kerja

Syarat-syarat pembayaran:

T/T, W, Western Union, MoneyGram

Menyediakan kemampuan:

3000 pcs per minggu

Deskripsi Produk

AUO 7inch automotive lcd panel Screen Monitor C070VAN02.9 50Pin 480*800pixels 133PPI

Brand:AUO

Model P/N: C070VAN02.9

Diagonal Size: 7.0"

Panel Type: a-Si TFT-LCD, LCM

Resolution: 800×480(RGB), WVGA 133PPI

Pixel Format: RGB Horizontal Stripe

Active Area:152.4(W)×91.44(H) mm

Bezel Opening:155.65(W)×94.04(H) mm

Outline Dim. 167.3(H)×109.2(V) ×9.35(D) mm

Treatment Antiglare

Luminance :1000 cd/m² (Typ.)

Contrast Ratio: 1000:1 (Typ.) (TM)

View Direction: Symmetry

Response Time: 11/9 (Typ.)(Tr/Td)

Viewing Angle: 80/80/80/80 (Typ.)(CR≥10) Left / Right / Up / Down

Operating Mode: AHVA, Normally Black, Transmissive

IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Support Color 16.7M 99% sRGB

Light Source :WLED [7S2P] , 10K hours , W/O Driver

Weight: 166±10g

Designed For: Outdoor High Brightness, Automotive Display

Frame Rate: 60Hz

120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Touch Panel :Without

Interface Type Parallel RGB (1 ch, 8-bit) , 50 pins FPC

Power Supply: 3.3V (Typ.)

Environment Operating Temperature: -30 ~ 85 °C ;

Storage Temperature: -40 ~ 95 °C ;

Vibration Level: 2.9G (28.4 m/s²)
